Acute Myeloid Leukaemia

Clinical context

A patient with recurrent infections

At a glance

StainMGG

About Acute Myeloid Leukaemia

This blood film represents a haematological emergency. The appearance is clearly one of leukaemia - the white cell count is in the hundreds and the platelet count is very low. The white blood cells have a monomorphic, immature appearance with open chromatin, a prominent nucleolus and a high NC ratio. These are all blasts.

The reson this is more significant than a leukaemia with a lower white count is that the severity of the leukocytosis combined with the clumping make it much more likely the patient is suffering from a complication known as leukostasis. As if having leukaemia is not bad enough, this is a complication where the clumps of blasts occlude blood vessels and cause multi-organ damage ranging from visual loss to renal impairment. Without treatment, it is universally fatal. A blood film like this needs immediate escalation!

It is difficult on this film to determine the origin of the leukaemia. The blasts are quite uniform, normally a feature of lymphoid leukaemias however there is some heterogeneity in the nuclear contour, and even more suggestive of a myeloid lineage is that some of the blasts appear to be granular. I couldn't find any auer rods in the film.

There are occasional neutrophils, but those seen are hypogranular also suggesting a myeloid lineage for the pathology. Overall though, if you commented that this was leukaemia then that is a  good start - narrowing it down to myeloid is excellent. Of course, flow cytometry, bone marrow examination (and probably leukapheresis in this case) are the next steps.

Morphological features

Clump of Blasts

Clump of Blasts - Acute Myeloid Leukaemia

These blasts are clumped together. This is common in leukaemias where the abnormal cell surface markers can include adhesion molecules.

Pleomorphic Nuclei in Blasts

Pleomorphic Nuclei in Blasts - Acute Myeloid Leukaemia

These blasts have pleomoprhic nuclei, that is they have different nuclear shapes. This is a feature of myeloid but not lymphoid leukaemias.

Hypogranular Neutrophil

Hypogranular Neutrophil - Acute Myeloid Leukaemia

Pleomorphic Nuclei

Pleomorphic Nuclei - Acute Myeloid Leukaemia

Granular Blast

Granular Blast - Acute Myeloid Leukaemia

Most of the blasts in this film are undifferentiated, however some have granules and this is suggestive of an undifferentiated acute myeloid leukaemia.

Granular Blasts

Granular Blasts - Acute Myeloid Leukaemia

Most of the blasts in this film are undifferentiated, however some have granules and this is suggestive of an undifferentiated acute myeloid leukaemia.

Prominent Nucleolus

Prominent Nucleolus - Acute Myeloid Leukaemia

Most of the blasts here re undifferentiated without an obvious nucleolus, but some do have a prominent one;

See these findings at full magnification
